Unmatched battery COMPATIBILITY
The Moxin controller can support up to 32s Batteries (134.4 volts fully charged with the 120v controller option) allowing you to push the limits even further than before. Higher volts = less amps for the same power. Which increases battery efficiency and range.
Wheelie Mode - Anti-loop
The game changing technology that allows ANYONE to hold a wheelie like never before. Moxin has an angle sensor BUILT IN. This allows the controller to sense how high the wheel is off of the ground and hold it to a desired angle that can be adjusted by the angle knob on your handlebars. You can still adjust it or disable the mode to allow you to loop, or adjust it so you cannot get the wheel off the ground at all.
Power Modes
Create and adjust up to 3 different power modes for different styles of riding. Throwing a beginner on the bike? Set it to "mode 1" where you can set desired power and speed limitations. Want to humble someone in a race? Set it to "mode 3" and leave them in the dust.
Controller Protection
Protecting your controller, battery, and motor from unnecessary wear and errors is important. The Moxin controller allows you to setup limitations for temperatures and voltages to keep your battery, motor and controller from overheating and causing any issues when out riding.
CHOICE OF SCREEN SIZES
Moxin gives you the option of 3 different screen sizes
3 inch - to stay out of the way
5 inch - Easy to read while riding
7 inch - If you like to flex
Real Time data
The real time data screen will show you advanced data that can assist with troubleshooting many issues. Testing to see if your throttle or hall sensor is bad has never been easier. This data page on your screen will list key data including: Controller Temp, Motor Temp, Throttle Input Voltage, Regen Brake Voltage, Battery Voltage, RPM, Phase Current, and much more.
IP68 WATER RESISTANCE
Moxin has done extensive testing of the controller in water. The IP68 Rating means this controller is resistant to fine particle dust and waterproof up to 10 meters for 30 minutes.
Self MOTOR LEARNING
The moxin controller has a self learning mode that will configure itself to your specific motor. This allows the Moxin controller to be compatible with a wide variety of motors including:
Stock Surron Light Bee X motor (Hall)
Stock Surron Ultra Bee motor (Encoder)
Stock E-Ride motor (Encoder)
Stock Talaria Sting R motors
KO Motors (Hall)
QS motors (Encoder)
EBMX XLB AND XUB motors (Hall)
Sotion motors (Encoder)
More motor testing soon (List will be updated when confirmed working)
80v cONTROLLER sPECS
Rated voltage: 48V-80V(12s-22s)
Peak phase current : 1100A
Rated power: 16kW
Peak power (10s): 80V * 770A= 61.6kW
Max efficiency: 96%
IP68
Warranty: 1 year
Operating Temperature Range: -40°C to 75°C
Motor Control Protocol: Field Oriented Control
120v cONTROLLER sPECS
Rated voltage: 48V-120V(12s-32s)
Peak phase current : 1000A
Rated power: 21kW
Peak power (10s): 120V * 700A= 84kW
Max efficiency: 96%
IP68
Warranty: 1 year
Operating Temperature Range: -40°C to 75°C
Motor Control Protocol: Field Oriented Control
bIKE COMPATIBILITY
Installs Directly (Plug & Play) on Surron Light Bee X and Surron Ultra Bee
TALARIA Sting, TALARIA X3, 79bike Falcon, E-ridepro SS confirmed working, but some pin modifications are required and custom mounting brackets will need to be made. Moxin Wheelie Controller
